How To Install Tea Cup Ride?

Installing a tea cup ride requires standardized construction processes and scenario-specific adjustments, whether you are setting up a regular model, a tea cup ride of China for commercial venues, or a themed tea cup ride wonderland facility for immersive amusement parks. Below is the step-by-step implementation framework.

First, confirm site conditions and core parameters before construction. For all models, verify that the installation site has a flat, hardened concrete foundation with load-bearing capacity no less than 300kg per square meter, and reserve 1-2 meters of buffer space around the planned equipment area. For tea cup ride of China models, cross-check the equipment size, power supply requirements and component list with the supplier in advance to avoid mismatch with local voltage specifications. For tea cup ride wonderland themed models, confirm the reserved positions for decorative elements, lighting systems and audio equipment during site measurement to align with the overall themed design.

Start with the base and central turntable assembly first. Fix the main support frame of the turntable to the pre-reserved embedded parts on the concrete foundation, tighten all anchor bolts to the torque value specified in the manual, and test the levelness of the turntable with a level gauge to ensure the deviation is less than 2mm. Next, install the transmission system including motors, reducers and hydraulic components, connect the transmission shaft to the turntable, and conduct a 30-minute no-load test of the transmission system to check for abnormal noise or vibration. Then, fix each cup cockpit to the corresponding position on the turntable, install the central steering wheel inside each cockpit, and test the independent rotation function of each cup to ensure smooth rotation without jamming. For tea cup ride of china models, pay extra attention to the connection of the control circuit, and adjust the voltage converter if needed to match local power grid standards. For tea cup ride wonderland models, install themed decorative shells, ambient lighting and background audio systems after the mechanical structure is installed, and test the linkage effect of lighting and audio with the operation of the ride.

Conduct layered testing before putting into operation. First, carry out 8 hours of continuous no-load testing, recording the operation status of the turntable, the rotation flexibility of each cup, and the sensitivity of the emergency stop button. Then conduct 4 hours of load testing with simulated weight equivalent to the maximum passenger capacity, checking whether the base has settlement, whether the transmission system has abnormal temperature rise, and whether the braking system responds accurately. For tea cup ride of china models, conduct an additional insulation resistance test of the electrical system to ensure compliance with local safety specifications. For tea cup ride wonderland models, test the stability of decorative parts under full-load operation to avoid loosening or falling off during operation. Finally, organize the acceptance according to local amusement facility safety standards, and prepare operation and maintenance manuals for subsequent management.
