What are the requirements for installing a drop tower in the amusement park?

First, the installation site must have sufficient space and geological conditions. The core installation area should reserve at least 1.5 times the equipment footprint as the buffer zone around the Drop tower ride, and the site foundation must be a reinforced concrete structure with a load-bearing capacity of no less than 500kN per square meter, without underground voids or soft soil layers. For high-altitude Amusement park drop tower models, the site should be located outside the take-off and landing clearance of nearby airports, and the wind resistance design of the equipment must meet the local maximum 100-year return period wind speed standard. The site should also be kept more than 50 meters away from high-voltage transmission lines and residential areas to avoid noise and light interference to the surrounding environment.

During the installation process, the main structure of the Drop tower amusement ride must be assembled in strict accordance with the design drawings, and all high-strength bolts must be tightened with a torque wrench to the specified value, with a random sampling inspection rate of no less than 30% ]. The verticality deviation of the main tower should be controlled within 1/1000 of the tower height, and the track joint flatness deviation should not exceed 0.5mm. After the mechanical structure is installed, the power supply and control system must be connected with an independent dedicated circuit, equipped with dual power supply switching devices and emergency stop systems covering the whole process of equipment operation. Before the initial operation, a 72-hour continuous no-load test and a 48-hour full-load simulation test must be carried out to record the operation stability of the lifting system, braking response speed and abnormal vibration data, and the test can only be passed if all indicators meet the safety standards.

After the installation is completed, the equipment must be inspected and accepted by the local special equipment safety supervision department, and the operation permit can be obtained before it is open to the public. The operator must be equipped with at least 2 professional personnel who have received special equipment operation training, and formulate a complete emergency response plan for equipment failure, power outage, extreme weather and other scenarios, and conduct no less than 2 emergency drills every quarter. For Amusement park drop tower models with a height of more than 30 meters, a real-time structural health monitoring system must be installed to continuously track the stress and deformation of the tower structure, and regular inspection reports must be submitted to the supervision department every year.
